The Napier plate. Relief from Copernicus GLO-30; rivers and lakes from USGS NHD; watersheds from the USGS Watershed Boundary Dataset; roads and city limits from Census TIGER 2024.
Partly cloudy
Mostly cloudy; warmer
Partly cloudy
Sunny
Sunny
Mostly sunny
Mostly sunny
Napier’s center stands about 1,490 ft above sea level. Within three miles the land runs from 1,170 ft to 1,790 ft, a difference of 620 ft: hilly country. The highest named summit within 15 miles is Round Top, about 2,800 ft, 13 miles north.
Under the town center the state geologic map shows Onondaga and Old Port Formations, undivided, from the Early Devonian to Middle Devonian, 384 to 422 million years old.
The section below crosses 13 rock units mapped at the surface.
Heights every 0.1 mile from the Copernicus GLO-90 surface model; vertical exaggeration about 10×. The colored band under the surface is the rock the state geologic map shows at the surface, not a picture of what lies beneath.
Shale. Age: Carboniferous, 299 to 324 million years old. About 4 mi of the line.
Black-shale. Age: Early Devonian to Middle Devonian, 384 to 422 million years old. About 3 mi of the line.
Siltstone, shale. Age: Late Devonian, 359 to 384 million years old. About 3 mi of the line.
Age: Early Devonian to Middle Devonian, 384 to 422 million years old. About 3 mi of the line.
Sandstone, conglomerate. Age: Carboniferous, 299 to 324 million years old. About 2 mi of the line.
Siltstone. Age: Late Devonian, 359 to 384 million years old. About 2 mi of the line.
From the USGS State Geologic Map Compilation (Horton and others, 2017), the states’ geologic maps joined at a common scale. 7 smaller units along the line are not listed.
Heights from Copernicus GLO-90 (a surface model: it includes buildings and tree canopy); summits from USGS GNIS; rivers from USGS NHDPlus HR; rock from the USGS State Geologic Map Compilation.
A raindrop that lands in Napier reaches Chesapeake Bay and the Atlantic Ocean by way of Shawnee Branch, the Raystown Branch Juniata, the Juniata and the Susquehanna: about 290 river miles.
Lakes on the way: Lake Aldred and Raystown Lake.
90 miles of the trip are on the Juniata.
Traced down the USGS NHDPlus V2.1 river network from the Census center point of Napier; river miles along the main stem, rounded.
